HPE Aruba AP-215 JW170A access point Wi-Fi 5
Tech specs:
⦁ Wireless Standard: 802.11a/b/g/n/ac(Wi-Fi 5)
⦁ Frequency Bands: 2.4 GHz, 5 GHz
⦁ Max Data Rate: 1.75 Gbps
⦁ Ethernet Ports: 1x 1 Gbps (Poe)
⦁ Antenna: Internal (6 omni-directional)
⦁ MIMO: 3×3 MIMO
Condition : Used
Aruba AP-215 802.11n/ac Dual 3×3:3 Radio Integrated Antenna AP
- HP Aruba Instant AP-215 (RW)Multifunctional and affordable Aruba 210 series wireless access points (APs) maximize mobile device performance in medium-density, high-performance Wi-Fi environments. These compact and cost-effective dual-radio APs deliver wireless data rates of up to 1.3 Gbps to 5-GHz devices with 802.11ac technology.
- The 210 series support your choice of operating modes to meet unique management and deployment requirements. Controller-managed AP or Remote AP (RAP) running Aruba OS. When managed by Aruba Mobility Controllers, 210 series APs offer centralized configuration, data encryption, policy enforcement and network services as well as distributed and centralized traffic forwarding. Aruba Instant AP running Instant OS. In Aruba Instant mode, a single AP automatically distributes the network configuration to other Instant APs in the WLAN. Simply power-up on Instant AP, configure it over the air, and plug in the other APs the entire process takes about five minutes
- Multifunctional and affordable Aruba 210 Series Access Points (APs) maximize mobile device performance in medium-density, high performance Wi-Fi environments, providing a cost-effective gigabit Wi-Fi solution for the enterprise. These compact and cost-effective dual-radio APs deliver wireless data rates of up to 1.3 Gbps to 5-GHz devices with 802.11ac technology. They also support 3×3 MIMO with three spatial streams as well as 2.4-GHz 802.11n clients at data rates up to 450 Mbps.
Other Interfaces
- One 10/100/1000BASE-T Ethernet network interface (RJ-45)
- Auto-sensing link speed and MDI/MDX
- 802.3az Energy Efficient Ethernet (EEE)
- PoE-PD: 48 Vdc (nominal) 802.3af or 802.3at PoE
- DC power interface, accepts 1.7/4.0-mm center-positive circular plug with 9.5-mm length
- USB 2.0 host interface (Type A connector)
- Visual indicators (LEDs):
- Power/system status
- Ethernet link status (ENET)
- Radio status (two; RAD0, RAD1)
- Reset button: factory reset (during device power-up)
- Serial console interface (RJ-45)
- Kensington security slot
Specifications
General
Weight: 21.51 oz (610 grams)
Networking
- Form Factor: In-ceiling
- Connectivity Technology: Wireless
- Line Coding Format: CCK, 64 QAM, 256 QAM, BPSK, QPSK, 16 QAM
- Data Link Protocol: IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
- Spread Spectrum Method: OFDM, DSSS
- Frequency Band: 2.4 GHz, 5 GHz
- Performance: Maximum data rate (2.4 GHz): 450 Mbps ¦ Maximum data rate (5 GHz): 1.3 Gbps
- ‘Capacity: Wireless clients per Wi-Fi radio: 255 ¦ BSSIDs per radio: 16
- Status Indicators: Power, system, wireless, link/activity
- Features: Auto-uplink (auto MDI/MDI-X), DFS support, MIMO technology, Quality of Service (QoS), Trusted Platform Module (TPM), reset button, Maximum Ratio Combining (MRC), 3T3R MIMO technology, Low Density Parity Check (LDPC), Transmit Beam-forming (TxBF) ready, Energy Efficient Ethernet, Cyclic Delay Diversity (CDD), Space Time Blocking Code (STBC), Advanced Cellular Coexistence (ACC), ClientMatch, cyclic shift diversity (CSD), wireless intrusion protection, Air Monitor (AM)
- Compliant Standards: IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at, IEEE 802.3az, IEEE 802.11ac
Expansion / Connectivity
- Interfaces: 1 x 1000Base-T (POE) – RJ-45 ¦ 1 x console – RJ-45 ¦ 1 x USB 2.0
Power
- Power Consumption Operational: 14.9 Watt
Environmental Parameters
- Min Operating Temperature: 32 °F
- Max Operating Temperature: 122 °F
- Humidity Range Operating: 5 – 95% (non-condensing)
Minimum Software Versions
- ArubaOS 6.4.2.0
- Aruba InstantOS 4.1.1.0
Antennas
- AP-215: Six integrated downtilt omni-directional antennas for 3×3 MIMO with maximum antenna gain of 5.0 dBi in 2.4 GHz and 5.0 dBi in 5 GHz. Built-in antennas are optimized for horizontal ceiling mounted orientation of the AP. Downtilt angle for maximum gain is roughly 30 degrees.
“Want to learn more? Click here to download the document!”
| Product Code |
JW170A |
|---|---|
| Serial Number |
raw05 |
| Management Port |
Yes |
| Wifi standard |
IEEE 802.11a/b/g/n/ac |
| WiFi Bands |
Dual band (2.4 GHz and 5 GHz) |
| Mimo Configuration |
3×3:3 |
| Maximum Data Rates |
Up to 1.3 Gbps (5Ghz) |
| Multi-User MIMO (MU-MIMO) |
Not supported |
| OFDMA |
Not supported |
| Target Wake Time (TWT) |
Not supported |
| Integrated lot Radios |
Not available |
| Expansion & Connectivity |
• 1 x Gigabit Ethernet (PoE) – RJ-45 |
| USB ports |
USB 2.0 host interface |
| Power Over Ethernet (PoE) Supported |
802.3af PoE |
| Maximum Associated Clients per Radio |
UP to 255 clients per radio |
| Radio coverage |
Dual-radio support for 2.4 GHz and 5 GHz bands with internal omni-directional antennas |
| Theoretical Total Clients |
510 |
| Recommended Clients |
75-100 Client per radio |
| Coverage Area |
Approximately 150-200 m (varies based on environment and deployment) |
| Power Consumption |
14.9 W |
| Input Voltage |
48V DC |
| Throughput |
Up to 1.75 Gbps |
| Internal Antennas |
6 internal antennas Omni-directional |
| Wireless Transmission Speed |
2.4 GHz: Up to 450 Mbps |
| Operating System |
ArubaOS |
| Encryption Algorithms |
WPA2, WPA3, AES |
| Dimensions ( WxDxH ) |
7.1 in x 7.1 in x 1.8 in |
| Weight |
21.51 oz (610 grams) |
| Wireless Communication Standard |
IEEE 802.11ax (Wi-Fi 5) |
| Spread Spectrum Method |
OFDM, DSSS |
| Environmental Conditions |
⦁ Temperature: 32 °F to 122 °F (0 °C to +50 °C) |
| Communications Technology |
Multi-User MIMO (MU-MIMO), Transmit Beamforming (TxBF) |
| Data Transfer Rate |
Up to 1.75 Gbps |
| Capacity |
Wireless Clients: Up to 255 per radio |
| Wireless Security |
Built-in Trusted Platform Module (TPM), WPA2/WPA3 |
| Data Link Protocol |
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Compliant Standards |
FCC, UL 2043, EN 60950, EN 60601-1-2, IEEE 802.11a/b/g/n/ac |
| Warranty |
6 months |
