Dell EMC PowerEdge T620 8×3.5″ Technical Guide: Features, Specifications, and Performance Overview

The Dell EMC PowerEdge T620 8×3.5″ server is a versatile and high-performance 5U rackable tower server designed to meet the demands of modern data centers and enterprise environments. With robust hardware configurations, flexible storage options, and advanced security features, the PowerEdge T620 is built to deliver exceptional reliability and scalability.

This technical guide covers the detailed features, specifications, and performance aspects of the Dell EMC PowerEdge T620 8×3.5″, helping IT professionals and system administrators understand its capabilities and deployment options.

Overview of Dell EMC PowerEdge T620 8×3.5″

The Dell EMC PowerEdge T620 supports up to 8 hot-plug 3.5-inch drives, providing significant storage capacity ideal for data-intensive applications. It is designed for scalability, featuring options for up to 12 3.5-inch drives or up to 32 2.5-inch drives, configurable in both tower and rack-mounted chassis. The system cannot be converted from tower to rack or vice versa post-purchase, so it’s essential to choose the configuration based on current and future infrastructure needs.

Key Technical Specifications of the Dell EMC PowerEdge T620 8×3.5″

Processor and Performance

At its core, the PowerEdge T620 is powered by the Intel Xeon E5-2600 v2 processor family. These processors offer up to 12 cores per CPU, with a 30MB cache, delivering up to a 40% performance improvement over previous generations. The system supports dual processors, enabling a maximum computational horsepower that can handle demanding workloads with ease.

• Processor Family: Intel Xeon E5-2600 v2 series

• Max Cores: Up to 12 cores per processor

• Cache: Up to 30MB

• Memory Speed: DDR3 1866MT/s

• Max Memory Capacity: Up to 768GB with 24 DIMM slots supporting up to 32GB DIMMs

Memory Features

The PowerEdge T620 supports Dell’s Fault Resilient Memory technology, which protects critical memory areas for hypervisors, improving virtualization reliability without consuming large amounts of RAM. This technology, combined with Failsafe Virtualization, ensures higher availability and protection for virtualized environments.

Storage and Drive Options

The Dell EMC PowerEdge T620 8×3.5″ chassis supports hot-plug drive bays, allowing for easy addition and replacement of drives without powering down the server.

• Drive Bays: 8x 3.5″ hot-plug bays (expandable to 12 or 32 bays depending on configuration)

• Drive Types Supported: SAS, SATA, SSD

• Storage Controllers: Internal and external storage controller options

• Optical Drive Support: Optional DVD drives available

• Tape Drive Support: Available for backup needs

Chassis Design and Features

The chassis of the PowerEdge T620 is designed for flexibility and accessibility. It includes updated industrial design features such as:

• Interactive LCD panel and control buttons for real-time system status and error diagnostics

• Tool-less ReadyRails™ II sliding rails for easy mounting in various rack types (4-post racks with square, round, or threaded holes)

• Front access for vFlash media reader enabling quick boot and recovery options

• Front VGA port on rack models for direct monitor connection

The server also includes several USB connectors (two front, six rear) and PCIe slots supporting up to seven expansion cards, allowing for customization and future upgrades.

Security Features of Dell EMC PowerEdge T620 8×3.5″

Security is a critical aspect of the PowerEdge T620 design. The server includes multiple features to protect data and hardware integrity:

• Cover Latch: A tooled latch securing the chassis cover to prevent unauthorized access.

• Optional Locking Front Bezel: Protects the hard drives and optical drives from unauthorized removal.

• Trusted Platform Module (TPM) 1.2: Enables secure key storage, password protection, and supports encryption technologies like BitLocker.

• Intrusion Alert: Detects chassis intrusion events.

• Power-Off Security: Allows disabling of the power button function through BIOS.

• Secure Boot Mode: Locks out power and NMI buttons, with system password protection options.

Conclusion

The Dell EMC PowerEdge T620 8×3.5″ server is a powerful, scalable, and secure solution suitable for businesses seeking a versatile rackable tower server with flexible storage options. Its advanced processors, extensive memory support, and robust chassis design make it ideal for virtualization, database management, and enterprise applications.

For those looking to deploy a high-performing, reliable, and easily manageable server, the Dell EMC PowerEdge T620 remains a compelling choice, supported by Dell’s comprehensive documentation and support infrastructure.

For more details, you can view the data sheet on our website using the following link: Spec sheet
